ON-BOARD DIAGNOSTIC
01–02–3
01–02
Meaning of fuel system loop status
• The following information is displayed on the tester.
— Feedback operating: HO2S being used for feedback is normal.
— Feedback stops: ECT is lower than the determined feedback zone.
— Feedback stops: Open loop due to driving condition.
— Feedback stops: Open loop due to detected system fault.
On-board system readiness test
• The items supported by the on-board system readiness test are shown below.
Continuous monitoring system
— HO2S heater
— Thermostat
— Fuel system
— Misfire
— CCM
Intermittent monitoring system
— HO2S
— AIR system
— Catalyst
— EVAP system
Sending Freeze Frame Data
• The Freeze Frame Data monitor items are shown below.
Freeze Frame Data monitor table
—: Not applicable
Full names Unit
DTC that caused required Freeze Frame Data storage —
Fuel system loop status Refer to list below.
LOAD %
ECT °C °F
Short term fuel trim %
Long term fuel trim %
Engine speed rpm
Vehicle speed km/h mph
Spark advance °
IAT °C °F
MAF g/s
Absolute TP %
AIR control status —
Time since engine start s
Purge solenoid valve control signal %
Fuel tank level %
Number of warm-ups since DTCs cleared —
Distance travelled since DTCs cleared km miles
BARO kPa
Estimated catalyst converter temperature °C °F
PCM power supply voltage V
Lambda —
Absolute load value %
Relative TP %
TP from TP sensor No.2 %
APP from APP sensor No.1 %
APP from APP sensor No.2 %
Throttle actuator control signal %
