Mazda RX-8 2004 - STEERING; 06-00 OUTLINE; STEERING FEATURES

06–00–1
06
STEERING
SECTION
06–00
Toc of SCT
OUTLINE . . . . . . . . . . . . . . . . . .06-00
ON-BOARD DIAGNOSTIC . . . . 06-02
ELECTRIC POWER
STEERING (EPS). . . . . . . . . . 06-13
Toc of SCT
06–00 OUTLINE
STEERING ABBREVIATIONS . . . . . . . . . 06–00–1
STEERING FEATURES . . . . . . . . . . . . . . 06–00–1
STEERING SPECIFICATIONS . . . . . . . . 06–00–1
End of Toc
STEERING ABBREVIATIONS
CHU060001034S03
End Of Sie
STEERING FEATURES
CHU060001034S01
End Of Sie
STEERING SPECIFICATIONS
CHU060001034S02
End Of Sie
ABS Antilock Brake System
CAN Controller Area Network
CM Control Module
CPU Central Processing Unit
DSC Dynamic Stability Control
EPS Electric Power Steering
HU Hydraulic Unit
IG Ignition
M Motor
OFF Switch Off
ON Switch On
PID Parameter Identification
SW Switch
WDS Worldwide Diagnostic System
Improved handling
Improved fuel economy
Improved marketability
• Rack assist EPS (Electric Power Steering) adopted
Improved operability • Steering shaft with a tilt mechanism adopted
Improved safety • Steering shaft with an energy absorbing mechanism adopted
Improved serviceability • Enhanced malfunction diagnosis system for use with WDS or equivalent
Item Specification
Steering wheel
Outer diameter (mm {in}) 370 {14.6}
Lock to lock (turns) 2.99
Steering shaft
Shaft type Collapsible design
Coupling type Cross-shaped joint design
Tilt amount (mm {in}) 32 {1.3}
Steering gear and linkage
Type Rack and pinion design
Rack stroke (mm {in}) 79.0 {3.11} x 2
Power steering Power assist system Electric motor assist (rack assist type)
