EMISSION SYSTEM
01–16–2
EMISSION SYSTEM STRUCTURAL VIEW
CHU011601007S02
End Of Sie
CATALYTIC CONVERTER SYSTEM OUTLINE
CHU011620500S01
Features
• Purifies toxic substances in exhaust gas by utilizing the chemical reaction process of the three-way catalyst.
End Of Sie
AIR CONTROL VALVE
AIR SOLENOID VALVE
CATCH TANK
VACUUM CHAMBER
AIR PUMP
VENTILATION
HOSE
QUICK RELEASE CONNECTOR
TWC
PURGE
SOLENOID VALVE
CHU0116S001
AIR FILTER
EVAPORATIVE CHAMBER
CHARCOAL CANISTER
FUEL SHUT-OFF VALVE
ROLLOVER VALVE
EVAP SYSTEM
LEAK DETECTION PUMP
CHU0116S002
