DYNAMIC STABILITY CONTROL
04–15–19
04–15
DSC Indicator Light Operation
End Of Sie
DSC OFF SWITCH, DSC OFF LIGHT FUNCTION
CHU041566410S01
• The DSC OFF switch, located on the dashboard, allows for optionally enabling/disabling the DSC control at
driver discretion.
• The DSC OFF light, built into the instrument cluster, informs the driver that DSC control has been disabled by
operation of the DSC OFF switch.
End Of Sie
DSC OFF SWITCH, DSC OFF LIGHT OPERATION
CHU041566410S02
• When the DSC OFF switch is pressed to disable DSC control, the DSC OFF light illuminates.
End Of Sie
Item DSC indicator light condition
TCS, DSC not operating Not illuminated
TCS operating
Flashes (0.5 s intervals)
DSC operating
DSC INDICATOR LIGHT
CHU0415S013
DSC OFF LIGHT
CHU0415S014
