Mazda RX-8 2004 - Lubrication 01-11 Lubrication

LUBRICATION
01–11–1
01–11
01–11 LUBRICATION
LUBRICATION SYSTEM OUTLINE . . . . 01–11–1
Features. . . . . . . . . . . . . . . . . . . . . . . . 01–11–1
LUBRICATION STRUCTURAL VIEW. . . 01–11–1
LUBRICATION SYSTEM FLOW
CHART . . . . . . . . . . . . . . . . . . . . . . . . . 01–11–2
OIL FILTER CONSTRUCTION . . . . . . . . 01–11–2
OIL COOLER CONSTRUCTION. . . . . . . 01–11–2
OIL PAN CONSTRUCTION. . . . . . . . . . . 01–11–3
OIL STRAINER CONSTRUCTION. . . . . . 01–11–4
OIL PUMP CONSTRUCTION. . . . . . . . . . 01–11–4
METERING OIL PUMP
CONSTRUCTION/OPERATION . . . . . . . 01–11–5
Construction . . . . . . . . . . . . . . . . . . . . . 01–11–5
Operation . . . . . . . . . . . . . . . . . . . . . . . 01–11–6
Fail-safe function. . . . . . . . . . . . . . . . . . 01–11–6
End of Toc
LUBRICATION SYSTEM OUTLINE
CHU011101008S01
Features
End Of Sie
LUBRICATION STRUCTURAL VIEW
CHU011101008S02
End Of Sie
Reduced weight
• A compact oil filter adopted
• An oil strainer made of plastic adopted
• A thin oil pan made of steel adopted
Improved lubricity
• A two-rotor type trochoid oil pump adopted
• An electric type metering oil pump adopted
OIL COOLER
METERING OIL PUMP
OIL PAN
OIL FILTER
OIL PUMP
OIL LEVEL SWITCH
OIL COOLER*
*: HIGH POWER
OIL STRAINER
CHU0111S001
