SECONDARY AIR INJECTION (AIR) PUMP CONSTRUCTION/OPERATION
CHU011613811S02
• Mainly consists of a DC motor and fan.
• When the AIR pump relay is turned on due to a PCM signal, the motor drives the pump fan to discharge
secondary air.
End Of Sie
POSITIVE CRANKCASE VENTILATION (PCV) SYSTEM OUTLINE
CHU011613890S01
Features
• A closed system has been adopted.
End Of Sie
MOTOR
FROM ATMOSPHERE
: SECONDARY AIR FLOW
TO AIR CONTROL VALVE
CHU0116S007
PCM
M
4O
AIR PUMP RELAY
AIR PUMP
CHU0116S018
GASKET (AT) GASKET (MT)
CHU0116S022
