Mazda RX-8 2004 - On-Board Diagnostic System Pid;Data Monitor Function (Abs, Dynamic Stability Control); PID;DATA Monitor Table (Vehicles with ABS)

ON-BOARD DIAGNOSTIC
04–02–6
*1
: If the ignition voltage returns to normal, the light goes out.
*2
: If the ignition voltage returns to normal, control is enabled.
*3
: Light goes out if the malfunction is repaired.
*4
: Control enabled if the malfunction is repaired.
*5
: Illuminates if tire size data cannot be received.
*6
: Control is disabled if tire size data cannot be received.
End Of Sie
ON-BOARD DIAGNOSTIC SYSTEM PID/DATA MONITOR FUNCTION (ABS, DYNAMIC STABILITY
CONTROL)
CHU040243000S03
• The PID/data monitor function is used for optionally selecting input/output signal monitor items preset in the
ABS HU/CM or DSC HU/CM and reading them out in real-time.
PID/DATA Monitor Table (Vehicles with ABS)
CAN
communication
system
U1900
Not
illuminated
*5
Not
illuminated
Illuminated Illuminated
Control
enabled
*6
Control
enabled
Control
disabled
Control
disabled
U2516 Illuminated
Not
illuminated
Illuminated
Not
illuminated
Control
disabled
Control
enabled
Control
disabled
Control
disabled
Malfunction
location
DTC
number
Fail-safe function
Warning light illumination status Control status
WDS or
equivale
nt
Display
ABS
warning
light
Brake
system
warning
light (when
parking
brake is
released)
DSC
indicator
light
DSC OFF
light
ABS
control
EBD
Control
TCS
control
DSC
control
PID/data monitor item Input/output part
Unit/Condition
(Tester display)
ABS_LAMP ABS warning light On/Off
ABS_VOLT Battery V
ABSLF_I LF inlet solenoid valve On/Off
ABSLF_O LF outlet solenoid valve On/Off
ABSLR_I LR inlet solenoid valve On/Off
ABSLR_O LR outlet solenoid valve On/Off
ABSPMPRLY Pump motor relay On/Off
ABSRF_I RF inlet solenoid valve On/Off
ABSRF_O RF outlet solenoid valve On/Off
ABSRR_I RR inlet solenoid valve On/Off
ABSRR_O RR outlet solenoid valve On/Off
ABSVLVRLY Valve control relay On/Off
BOO_ABS Brake switch On/Off
BRAKE_LMP Brake system warning light On/Off
CCNTABS Number of continuous DTCs —
LF_WSPD ABS wheel-speed sensor (LF) KPH, MPH
LR_WSPD ABS wheel-speed sensor (LR) KPH, MPH
PMPSTAT Pump motor On/Off
RF_WSPD ABS wheel-speed sensor (RF) KPH, MPH
RR_WSPD ABS wheel-speed sensor (RR) KPH, MPH
