Mazda RX-8 2004 - Shift Interlock Mechanism Operation; In Neutral Position

MANUAL TRANSMISSION [Y16M-D]
05–11–7
05–11
SHIFT INTERLOCK MECHANISM OPERATION
CHU051101025S09
In Neutral Position
INTERLOCK BLOCK
MAIN SHIFT FORK SHAFT
SECTION A
SECTION C
INTERLOCK BLOCK
INTERLOCK BLOCK
INTERLOCK BLOCK
SHIFT FORK SHAFT No.2
SHIFT FORK SHAFT No.3
SECTION B
BALL
SECTION A
SECTION C
CHU0511S110
