INTAKE-AIR SYSTEM
01–13–2
INTAKE-AIR SYSTEM STRUCTURAL VIEW
CHU011300113S02
End Of Sie
VFAD ACTUATOR
(13B-MSP (HIGH POWER))
AIR CLEANER
CHECK VALVE
(13B-MSP (HIGH POWER))
THROTTLE BODY
SSV SOLENOID
VALVE
VDI SOLENOID
VALVE
CHECK VALVE
VFAD SOLENOID VALVE
(13B-MSP (HIGH POWER))
VACUUM CHAMBER
(13B-MSP (HIGH POWER))
RESONANCE CHAMBER
FRESH-AIR DUCT
VDI ACTUATOR
SSV ACTUATOR
APV MOTOR
(13B-MSP (HIGH POWER))
INTAKE MANIFOLD
(ILLUSTRATION SHOWS 13B-MSP (HIGH POWER))
CHU0113S001
