Mazda RX-8 2004 - HEATER, VENTILATION & AIR CONDITIONING (HVAC); 07-00 OUTLINE; HVAC FEATURES

07–00–1
07
HEATER, VENTILATION &
AIR CONDITIONING (HVAC)
SECTION
07–00
Toc of SCT
OUTLINE . . . . . . . . . . . . . . . . . .07-00
BASIC SYSTEM . . . . . . . . . . . .07-11
CONTROL SYSTEM . . . . . . . . 07-40
Toc of SCT
07–00 OUTLINE
HVAC ABBREVIATION . . . . . . . . . . . . . . 07–00–1
HVAC FEATURES . . . . . . . . . . . . . . . . . . 07–00–1
HVAC SPECIFICATIONS. . . . . . . . . . . . . 07–00–1
Basic System . . . . . . . . . . . . . . . . . . . . 07–00–1
Control System. . . . . . . . . . . . . . . . . . . 07–00–2
End of Toc
HVAC ABBREVIATION
CHU070001038S01
End Of Sie
HVAC FEATURES
CHU070001038S02
End Of Sie
HVAC SPECIFICATIONS
CHU070001038S03
Basic System
A/C Air Conditioning
B+ Battery Positive Voltage
CPU Central Processing Unit
HI High
IG Ignition
LO Low
M Motor
MAX Maximum
OFF Switch Off
ON Switch On
PCM Powertrain Control Module
REC Recirculate
Reduced weight • Integrated A/C unit adopted
Improved air conditioning
performance
• Sub-cooling system to multi-flow condenser adopted
Improved comfort • Air filter adopted
Item Specification
Heating capacity (kW {kcal/h}) 4.400 {3,784}
Cooling capacity (kW {kcal/h}) 4.500 {3,870}
Refrigerant
Type R-134a
Regular amount
(approx. quantity)
(g {oz}) 430 {15.2}
A/C compressor
Type Scroll type
Discharge capacity (ml {cc, fl oz}) 60 {60, 2.03}
Max. allowable speed (rpm) 9,000
Lube oil
Type DENSO OIL8
Sealed volume
(approx. quantity)
(ml {cc, fl oz}) 60 {60, 2.03}
