11 Device manager
900 Touch Control
￭￭￭￭￭￭￭￭
105
Input range 0 to 'maximum stroke path' mm
A lift position of 0 mm corresponds to the "home
position", i.e. the lift is located at the upper stop
position. The maximum stroke path is defined in the
properties of the tower (see "Maximum stroke
path", page 94).
Rinse position
Lift position used for rinsing.
Input range 0 to 'Maximum stroke path' mm
Default value 0 mm
A lift position of 0 mm corresponds to the "home
position", i.e. the lift is located at the upper stop
position. The maximum stroke path is defined in the
properties of the tower (see "Maximum stroke
path", page 94).
Shift position
The lift is raised to this position with each rotational movement of the rack
whenever it is located at a lower lift position.
Input range 0 to 'maximum stroke path' mm
A lift position of 0 mm corresponds to the "home
position", i.e. the lift is located at the upper stop
position. The maximum stroke path is defined in the
properties of the tower (see "Maximum stroke
path", page 94).
Special position
For sample positions, you can define an additional lift position for special
applications.
Input range 0 to 'maximum stroke path' mm
A lift position of 0 mm corresponds to the "home
position", i.e. the lift is located at the upper stop
position. The maximum stroke path is defined in the
properties of the tower (see "Maximum stroke
path", page 94).
Editing special beakers
Sample rack list: Rack ▶ Edit ▶ Special beakers
