ASAP 2460 Operator’s Manual Generating Graph Overlays
246-42800-01 - Aug 2013 2-55
4. On the Report Options tab, click the Overlays button.
• BET Surface Area
• Langmuir Surface Area
• Freundlich
•Temkin
•t-Plot
•Alpha-S
•f-Ratio
a.) In the Selected Reports list box, highlight one of the report
options shown on the left and click Edit.
b.) On the Report Options window, select the Overlay
samples checkbox for the Transform plot and/or the
Isotherm plot. Verify other fields. Click OK to return to the
Report Options tab.
c.) Continue with Step 4.
•BJH Adsorption
• BJH Desorption
• Dollimore-Heal Adsorption
• Dollimore-Heal Desorption
•MP-Method
a.) In the Selected Reports list box, highlight a report option
shown on the left and click Edit.
b.) Select the report variable from the Selected Reports group
box and click Edit.
c.) Click the dropdown arrow on the Overlay field and select
the Samples option. Verify other fields. Click OK to return
to the Report Options window.
d.) Click OK again to return to the Report Options tab.
e.) Continue with Step 4.
If overlaying this type of
report...
Then... (continued)
