ASAP 2460 Operator’s Manual Generating Graph Overlays
246-42800-01 - Aug 2013 2-61
3. From the Report Options window, in the Selected Reports list box, select a sub-report and click
Edit.
4. Click the dropdown arrow at the Variable field and select a variable to overlay. Then click the
dropdown arrow of the Overlay field and select the Imported Data entry. Click OK to return to
the Report Options window.
5. Click OK again to return to the Report Options tab.
6. Click Save to save the selections.
Select a sub-
report
Click Edit
Displays the first
report variable
Select the second
variable from the
dropdown list
To Next Page
