10 - 14
1. Screen: displays the Temp readings and measurement mode
2. Mode button: sets the measurement mode to Forehead or Body
3. Battery compartment: installs two AAA batteries
4. Start Measurement button: press it to turn the thermometer on and perform a
Temp measurement
5. Infrared sensor window: detects the temperature
10.6.2 Taking a Temperature with HeTaida Thermometer
To take a temperature with Hetaida Thermometer, follow this procedure:
1. Set the thermometer to Forehead mode.
2. Point the infrared sensor window to the forehead of a patient.
3. Press the Start Measurement button and read measurement.
10.7 Manually Inputting Temp
You can manually input a Temp value and save the data for future reference.
Follow this procedure:
1. Select in the Temp area. For monitors configured with Mindray SmarTemp™
module, to input Temp value in Continuous Monitoring mode, press and hold
in the Temp area.
2. Select a Temp Measurement Site. The options displayed in the menu is
configurable. For details, refer to 18.9.3 The Temp Tab.
3. Input a measured Temp value.
4. Select the Save quick key to save the data.
