18 - 9
18.6.3 The Latching Tab
18.6.4 The Nurse Call Tab
Reminder
Tone
Reminder
Interval
5 min • 10 min: the monitor issues reminder
tones every 10 minutes.
• 5 min: the monitor issues reminder
tones every five minutes.
• 3 min: the monitor issues reminder
tones every three minutes.
• 2 min: the monitor issues reminder
tones every two minutes.
• 1 min: the monitor issues reminder
tones every one minute.
Section Menu Item
Default
Setting
Function
Menu Item Default Setting Function
High,
Med,
Low
Visible Unselected Selects alarm latching rules:
•If Visible is selected, you can separately
latch visual alarm signal.
•If Audible is selected, you can latch both
audible and visual alarm signals.
• Selecting alarms of lower priority
simultaneously latches higher priority
alarms.
Audible
Menu Item Default Setting Function
Signal Type Continuous • Pulse: the nurse call signal is a pulse signal and
each pulse lasts one second. When multiple
alarms simultaneously occur, only one pulse
signal is outputted. If an alarm occurs but the
previous one is not cleared, a new pulse signal
will also be outputted.
• Continuous: the nurse call signal lasts until the
alarm ends. That is to say the duration of a nurse
call signal is equal to that of the alarm condition.
Contact Type Normally Open Selects the work mode of the nurse call relay
To Next Page
