3 - 9
4. Quick key area: displays quick keys. These keys may vary according to the work-
flow settings.
5. Alarm information area: displays physiological alarms on the above, and prompt
messages and technical alarms at the bottom.
6. System status information area: displays symbols indicating the battery status,
network status, blue tooth status etc.
7. System time: displays the current system time.
8. Clinician information: displays login information of clinician. Select this area to log
in or out.
3.8.2 Menus
All menus have similar style and structure, see the figure below:
1. Menu heading
2. Tabs: enters submenus
3. Main body area: includes menu items and options.
4. Operation buttons
5. Exit button: closes the current menu page.
6. Switch:
◆ Green: the switch is on.
◆ Gray: the switch is off.
