A - 5
A.5.3 Recorder Specifications
A.5.4 LEDs
A.5.5 Audio Indicator
A.5.6 Monitor Interface Specifications
A.5.7 Outputs Specifications
Resolution 1024×768 pixels
Method Thermal dot array
Paper speed 25 mm/s
Alarm lamp 1 (three color coded: cyan, yellow and red)
Power on LED 1 (green)
AC power LED 1 (green)
Battery LED 1 (two color coded: yellow and green)
Speaker Give alarm tones (45 to 85 dB), key tones, pulse tone; power-on
self-check tone, support PITCH TONE and multi-level tone
modulation; alarm tones comply with IEC60601-1-8.
Power 1 AC power input connector
Wired network 1 RJ45 connector
USB 2 standard connectors, USB 2.0, type A
Equipotential Grounding Terminal 1
Multi-Functions Connector 1
External battery connector 1
Nurse Call Signal
Amplitude High level: 3.5 to 5 V, ±5%, providing a minimum of 10 mA
output current
Low level: <0.5 V, receiving a minimum of 5 mA input current
Rising and falling time ≤ 1 ms
Alarm output (Network connector)
