13 - 3
3. Switch on RR.
13.5.3 Setting RR Alarms
In Continuous Monitoring mode, you can set the RR alarm limits. Follow this procedure:
1. Select the CO
2
numeric area or waveform area to enter the CO2 menu.
2. Select Alarm tab.
3. Set the high and low limits and the priority in the RR row.
13.5.4 Setting the Apnea Alarm Delay
The monitor will alarm if the patient has stopped breathing for longer than the preset
Apnea time.
In Continuous Monitoring mode, you can set the Apnea delay time, follow this
procedure:
1. Select the CO
2
numeric area or waveform area to enter the CO2 Setup menu.
2. Select Apnea Delay and then select the appropriate setting.
13.5.5 Setting Timer Interval
A timer is provided when manually inputting RR value. A reminder is given at a set
interval to assist in counting of Resp number. To set the timer reminding interval for
manual RR, follow this procedure:
1. Select the Main Menu quick key → from the Configuration column select
Workflow → input the required password → select .
2. Select on the right of the workflow to be set.
3. Select Parameters Setup → RR tab.
4. Set Timer Reminder Interval as needed.
