16 - 2
■ Select on the current page.
In Spot Check mode, to start a recording:
1. Select the Save quick key.
2. Select on the current page.
16.3 Stopping Recordings
Recordings can be stopped manually or automatically.
16.3.1 Stopping Recordings Manually
To manually stop a recording, choose either of the following method:
■ Press the hardkey again.
■ Select the Main Menu quick key → from the Device column select Record Setup,
and then select Clear All Record Tasks.
16.3.2 Stopping Recordings Automatically
Recordings stop automatically in the following conditions:
■ The recording is completed.
■ The recorder runs out of paper.
■ The recorder has an alarm condition.
16.4 Recording Related Flags
You can find the following flags on the recording reports:
■ For automatically stopped recordings, there are two columns of asterisks “*” at the
end of the report.
■ For manually or abnormally stopped recordings, there is one column of asterisks
“*” at the end of the report.
16.5 Setting the Recorder
To set the recorder, follow this procedure:
1. Select the Main Menu quick key → from the Device column select Record Setup.
2. In the Record Setup menu, select the desired waveform for Waveform 1 and
Waveform 2 in turn. The recorder can record up to 2 waveforms at a time.
3. Select Recording Duration to set the duration of real-time recording.
4. Select Recorder Paper Speed to set the speed for recording waveforms.
