[Max] (maximum capacity)
The maximum capacity that can be measured without a dead load.
For description and settings, refer to Chapter 4.7.1.2.1.1.
[Scale interval]
The scale interval (d) is the dierence between two successive display values.
For description and settings, refer to Chapter 4.7.1.2.1.2.
[Dead load at]
Use an empty scale or vessel as the dead load (normal case).
For description and settings, refer to Chapter 4.7.1.2.1.3.
[Max at]
Perform calibration with weights, without weight (by mV/V values or data), or
linearization, see Chapter 4.7.1.2.1.4.
- [by load], see Chapter 4.7.1.2.1.4.1.
- [by mV/V], see Chapter 4.7.1.2.1.4.2.
- [by data] Load cell data (smart calibration), see Chapter 4.7.1.2.1.4.3.
- [Linear.] (linearization), see Chapter 4.7.1.2.1.4.4.
WP-A Max 3000g d= 0.1g
00
+
g
Calibration @admin
1
2
3
Max
Scale interval
Dead load at
Max at
calibrated with mV/V
Sensitivity
3000.0 g
0.1 g
mV/V
mV/V
mV/V
µV/d
0.040582
1.177264
1.177264
0.470906
30000 d
1 d
103.415 g
3000.000 g
98.11 cnt/d
by load by mV/V by data Linear. Save
WP-A Max 3000g d= 0.1g
00003
TST
+
Calibration @admin
1
2
3
Max
Scale interval
Dead load at
Max at
calibrated at
Sensitivity
3000.0 g
0.1 g
mV/V
mV/V
mV/V
µV/d
0.040750
1.177246
0.987513
0.470898
30000 d
1 d
102.832 g
3000.000 g
2516.5 g
98.11 cnt/d
by load by mV/V by data Linear. Save
Calculate the reference value
for the weighing electronics test...
This window appears briey.
The maximum capacity (Max) is displayed with the ID "TST" and without a weight unit.
4. Press the [Save] soft key to save the calibration.
