4.1.2 Camera Screens in the Browser
By factory default, the MOBOTIX camera first shows the Live screen. You can set a
different entry page in order to prevent others from changing settings; you can
assign user names and passwords to prevent unauthorized access or you can
restrict access to the current live image only, by setting the Guest screen as entry
page.
The following screens are available:
• Guest screen: Only shows the current live image with reduced frame rate.
• Live screen: Shows the current live image and allows changing the
image and event settings of the camera.
• Playback screen: Shows all recorded images or video clips with
extended functions for searching and downloading images, regardless
of where the images are stored (in the internal or the external ring buffer on
a file server or PC).
• MultiView screen: Shows multiple cameras or the last events in a freely
definable layout.
• PDA screen and PDA Event List: Both screens are optimized for PDAs with a
focus on fast data transmission with low bandwidth requirements (GSM,
GPRS) on devices with small displays (PDAs, mobile phones, sub notebooks).
The PDA Event List in particular gives a quick overview of the last events since
the live image of the camera is not transferred.
For more information on camera screens, see the online help of the camera's
browser interface. Click on the yellow icon in the top right corner of the Live
screen to open the corresponding page of the online help.
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com • 10.10.2006
Software Camera Manual Part 2
Use the Administration
menu to set the camera
screen that should appear
initially when accessing
the camera IP address
(Admin Menu> Language
and Entry Page)
http://10.1.0.99/pda
opens the PDA screen
Live/Playback/MultiView:
Click on to open the
online help pages for the
camera screens
Note
Open Admin Menu > Language and Entry Page to set a different
start page when accessing the camera.
Open Admin Menu > Users and Passwords and Admin Menu >
Group Access Control Lists to set user rights and to prevent unautho-
rized access to certain screens (see section 5.4.1,
Users, User Groups,
Passwords, Supervisor Mode
).
