Mobotix M22 - Placeholders and Variables in the Comment Field

• Object Tracing (OT): This parameter will identify up to five moving objects
and to highlight the
movement by dis-
playing the object
traces in different
colors.
5.5.4 Placeholders and Variables in the Comment Field
For detailed information on the placeholders and text variables in the comment
field that are available for your camera model and software version, see the cam-
era help (keywords:
placeholder, variables ) as well as the reference manual. The
following list contains a small selection:
• ~E: The current IP address of the camera's Ethernet interface
• ~H: Current host name of the camera
• ~N: The camera's factory default IP address
• ^IR: Illumination value of the right camera lens
• ^IL: Illumination value of the left camera lens
• ^Ti: Internal camera temperature in degrees Centigrade
• ^Ld: Date and time of the last image recording
• ^Ls: Time since last image recording in seconds
• ^s#: Display of RS232 data (# specifies the number of lines)
• ^#nn: Display of colored text with values for nn ranging from 00 (black) to
0F (white)
• $(ID.SWV): Software version of the camera
• $(SEN.TIN.FAHRENHEIT): Internal camera temperature in degrees Fahrenheit
• ^gx,y;: Free positioning of text using the parameters x and y (units are
character width and character height as displayed in the image; the zero
position is in the top left corner of the image).
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com • 10.10.2006
110/288
Software Camera Manual Part 2
The MOBOTIX camera
can trace a maximum of
five objects
simultaneously
Different objects are
displayed in different
colors
Placeholders and variables
insert dynamic texts
(refer to the camera help
and the reference manual
for more information on
this topic)
