7.6 Events
7.6.1 Event Selection
The Setup Menu > Event Settings dialog allows activating and configuring the
events that are detected by the camera. Use the More button to show all available
events. Most of the events have additional fields that are only displayed if the cor-
responding event has been activated. The MOBOTIX camera can detect and react
to the following events:
User Events
• UC: User Click
• BT: Camera key (Button)
• IR: IR remote control
Video Motion Events
• VM, VM2: Video Motion window
Hardware Sensor Events
• PI: PIR sensor (Passive-Infrared sensor)
• MI: Microphone
• IL: Illumination
• TP: Temperature
Signal and Exposure Events
• SI: Signal Input
• SIx: Additional signal input lines (SI2, SI3, SI4)
• RC:IP Receive (IP messages)
• CI: RS232 messages (COM In)
Time-Related Events
• PE: Periodic Event
• TT: Time
Task event
• RD: Random event
Recording Events
• RB: Recording Begin
• RE: Recording End
• RT: Recording Terminate
• RH: Recording History
Enhanced Events
• EC: Event filter, Event Counter (section 7.6.3)
• EL: Event Logic (section 7.6.4)
