Mobotix M22 - General Settings of the Recording Modes

b) Set the following parameters for Event Recording (MxPEG):
- Events, which will start a recording
- Event Frame Rate
(e.g. 12 frames per second)
- Record Audio Data (
Off or Include Audio )
c) Set the following parameters for Continuous Recording (MxPEG):
- Continuous Recording Frame Rate (e.g. 2 frames per second)
- Events, which are increasing the frame rate
- Event Frame Rate (e.g. 12 frames per second)
- Record Audio Data (
Off or Include Audio )
8.2.2 General Settings of the Recording Modes
• Arm Recording
• Enable : Activates recording.
•
Off : Deactivates recording.
•
SI Closed (low) : The camera only records if the signal output is closed.
•
SI Open (high) : The camera only records if the signal output is open.
In order to control the camera's arming status in a scheduled manner, you
can select one of the Time Table profiles. This selection box is available if
Arm Recording has been set to
Enable , SI Closed or SI Open (see also sec-
tion 7.8.6,
Time Tables ).
• Terminate Recording (TR)
This function will completely deactivate the camera recording after a preset
event has occurred (if configured, the recording will continue during the Time
Before Terminate).
Recording will be reactivated only after user intervention, e.g. by clicking on
the "
Click here to resume recording " link in Setup Menu > Recording. As an
alternative, you could define the Restart Actions softbutton to reactivate re-
cording (see section 4.9,
Configuring Softbuttons ).
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com • 10.10.2006
209/288
Software Camera Manual Part 2
Setup Menu> Recording
Note
Make sure that MxPEG has been activated in Setup Menu > JPEG
Settings. This will ensure that the MOBOTIX camera uses the highest
possible frame rate (see also section 4.10,
Fast Video Streaming ).
Caution
If Terminate Recording has temporarily deactivated the recording fea-
ture, images and video clips will only be recorded again, if you manu-
ally restart recording.
A terminated recording
has to be restarted
manually (link, softbut-
ton)!
