Recording has been activated and FS indicates external image storage on a file
server.
The symbols may assume different colors, thus indicating their status:
• Event symbols are red upon detection of an event and white otherwise.
• Action and message symbols are turquoise if an action or message is car-
ried out, red if an action or message failed (e.g. an uncompleted phone call),
and yellow otherwise. The symbols will turn grey if the action or message
profile has been deactivated (either manually or from a Time Table profile).
For failed actions, messages or recording, a yelow error message will
appear above the symbols (Setup Menu > Text and Display Settings >
Error Messages).
If you have selected a Time Table profile in Setup Menu > General Event
Settings to control the camera's arming, the additional off string in the bot-
tom right corner of the live image will signal that the camera has been tem-
porarily disarmed by a Time Table profile. If this is the case, all action, mes-
sage and recording symbols will be shown in gray.
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com • 10.10.2006
145/288
Software Camera Manual Part 2
For a complete list of all
symbols and color codes,
see the camera help and
the reference manual.
Status Color Example Event
Activated
Executing
White
Aqua
UC
UC
User Click
User Click
Deactivated Gray UC User Click
Status Color Example Action/Message
Activated
Executing
Yellow
Aqua
EM
EM
E-Mail
E-Mail
Deactivated
Error
Gray
Red
EM
EM
E-Mail
E-Mail
Caution
If the camera's arming has been deactivated in Setup Menu > Gen-
eral Event Settings (
Off
), all event, action and recording symbols are
missing from the live image.
