If Order of Occurrence has been set to
A->B
, the event from Event Set A has to
occur before the event from Event Set B. Selecting the
A<->B
option means that the
order of occurrence is irrelvant.
• Event Logic (EL): If activated, the camera can trigger EL events. The event
logic evaluates all events selected in the Event Set A and Event Set B lists.
• Maximum Time Window: Sets the time span within which the events from
the two event sets have to occur before the camera triggers an EL event (1
second to 15 minutes).
• Event Set A: Select the events, which have to occur first in order to trigger an
EL event. Make sure that the highlighted events have been activated in the
Setup Menu > Event Settings dialog if you intend to use them. If an event is
displayed gray and in parentheses, it has not been activated.
• Order of Occurrence: Set the order in which the events from the two event
sets have to occur in order to trigger an EL event. If the
A->B
option has been
selected, an event from Event Set A has to occur before an event from Event
Set B. If the
A<->B
option has been selected, the order in which the events
from the two event sets occur is irrelevant.
• Minimum Delay: Sets the minimum time span between an event from one
event set and an event from the other event set that has to pass before the
camera triggers an EL event (0 to 20 seconds).
• Event Set B: Select the events, which have to occur before or after the ones
selected in Event Set A in order to trigger an EL event. Make sure that the
highlighted events have been activated in the Setup Menu > Event Settings
dialog if you intend to use them. If an event is displayed gray and in paren-
theses, it has not been activated.
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com • 10.10.2006
168/288
Software Camera Manual Part 2
Logical linking of several
events
