Global Options
The Logo Display parameter is the main switch for all logo profiles. Disabling Logo
Display and clicking on the Set at the bottom of the dialog will remove all logos
from all camera images.
Profiles & Options
The dialog contains some sample profiles; you can change these profiles or add
new ones by clicking on Add new logo definition at the bottom of the dialog.
Enter the profile name in the Logo n field (where n is the current number of the
profile). Remember to enter a descriptive name as this name is later displayed in
other dialogs.
• Display Options:
- Enable Logo: Activates (
Show
) or deactivates (
Hide
) the logo profile.
- Time Table Profile: Select the desired time table profile if displaying the
logo should be controlled by a time table.
- Live Image Logo: This option allows using the logo for the live image of
the camera.
- Image Sizes: Select the image sizes (resolutions) on which the selected
logo(s) are to be displayed. The logo will only be displayed on the camera
image for the resolutions selected in this profile.
- Logo Opacity: This parameter controls how the logo will cover the cam-
era image (
100%
will cover the background completely,
10%
to
90%
will let
you see the camera image through the transparent logo).
• Image List:
Select the graphics files, which are to be displayed as logos one after the
other. Rotation Interval sets the interval, during which each logo is visible
(only if more than one graphics file has been selected).
• Logo Position:
- Positioning Mode
Relative
: Displays the logo at a relative position. The
logo position and the offset are specified using the X/Y Alignment
parameters (
Left
,
Center,
Right
) to set a reference, and the X/Y Offset
parameters.
- Positioning Mode
Frame
: Uses the logo as a frame, where the horizontal
frame width and the vertical frame height are set using the X/Y Border
parameters.
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com • 10.10.2006
196/288
Software Camera Manual Part 2
Activate the Logo Display
main switch!
Animated image sequences
in the live image
