• Start Recording, Event Frame Rate, Recording Time (optional): Highlight
the events in Start Recording that are supposed to increase the frame rate
to the value set in Event Frame Rate. Event Frame Rate sets the frame rate
for recording once an event has been detected. Recording Time specifies
the duration during which the camera increases the frame rate. The settings
for Start Recording and Recording Time are optional.
Make sure that the highlighted events are activated in the Setup Menu >
Event Settings dialog if you intend to use them.
• Retrigger Recording (optional): Highlight the events, which should retrigger
(i.e. extend) recording with increased frame rate. If one of the selected
events occurs, the camera extends recording with increased frame rate for
the time specified in Recording Time. This is an optional parameter.
Make sure that the highlighted events are activated in the Setup Menu >
Event Settings dialog if you intend to use them.
• Stop Recording, Recording Time After Stop Event, Recording Dead Time
(optional): Highlight the events, which should stop recording with increased
frame rate and return to the default frame rate. These parameters allow set-
ting the time recorded after a Stop Recording event (Recording Time After
Stop Event, max. five minutes) and the Recording Dead Time. The Record-
ing Dead Time prevents new recordings with increased frame rate after a
Stop Recording event has been detected. Note that the camera creates a
new recording sequence if one of the events selected in Start Recording oc-
curs, but only if the specified Recording Dead Time has been observed. The
settings for Stop Recording are optional.
Make sure that the highlighted events are activated in the Setup Menu >
Event Settings dialog if you intend to use them.
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com • 10.10.2006
215/288
Software Camera Manual Part 2
Events, which have not
been activated in Setup
Menu> Event Settings
are displayed "gray" and in
parentheses
Note
The Stop Recording function will only stop recording with the frame
rate set in Event Frame Rate. Recording itself will resume using the se-
lected Continuous Recording frame rate.
The Recording Begin (RB) event will only be triggered if one of the
events selected in Start Recordingg
gg
occurs. The Recording End (RE)
event will be triggered if recording with increased Event Frame Rate
switches back to the Continuous Recording frame rate.
