(2) Set the behavior of an image area:
Auto zoom: If this option is set to
On
, moving your mouse over this image
area will automatically enlarge this camera's image.
On Alarm: Use this option to set what should happen when the displayed
camera detects an event (alarm):
•
Highlight
: The image window will be colored in light red.
•
Message
: A colored browser window with more information will pop up.
•
Focus
: The image from the image area will be shown in a different image
area (e.g. enlarged). This requires that one of the image areas has been
set as Focus area (see below).
Note: You may select one of the combinations of
Highlight
,
Message
and
Focus
.
On Click: Use this option to define what should happen when you click on
the image area:
•
Goto Live Image
: Opens the Live screen of the corresponding camera in
the browser window.
•
Goto Player
: Opens the Playback screen of the corresponding camera in
the browser window.
•
Remote softbutton
: Executes the softbutton command selected in the
Softbutton box (e.g.
4x Zoom
activates the 4x soft zoom of the camera,
Quad
activates the Quad MultiView screen).
(3) Set the display options of an image area:
• Live Image (fast): Shows the current live image of the corresponding ca-
mera in the MultiView image area. The Refresh parameter is indepen-
dent of the frame rate set for the Live screen of the camera. If On Alarm
has been set to
Focus
, the image will also be displayed in the focus area
of the MultiView screen (see below).
• Special Format (slow): This option selects the image that is to be shown
(left or right image sensor for MOBOTIX Dual or Night models) and the
frame rate, both independent of any live image settings of the correspon-
ding camera. This setting is named "slow" since the camera has to crea-
te additional images with different settings besides the live images and
this process requires extra computing time.
• Event: Shows one of the last ten events in the image area (0 = last event,
1 = second but last event, ...). This option allows displaying a certain
number of events that are always present on the screen (as defined in
the Events MultiView window).
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com • 10.10.2006
40/288
Software Camera Manual Part 2
Automatic switching bet-
ween cameras in case of
an alarm (event) or tra-
cking of an event using
several cameras
Flexible display options
for every image area
