Description of Function Codes NICE1000
new
User Manual
- 156 -
5. For FA-26 to FA-37, LEDs 5 and 4 show the function No.; LED 3 shows whether the
function is valid (1) or invalid (0); the 16 segments of LEDs 1 and 2 show the states of the
16 functions in this parameter.
The preceding figure shows display of FA-16: LEDs 5, 4, and 3 show that function 10
(Inspection down) is 1 (Valid); LEDs 1 and 2 show that besides function 10, functions 4
(RUN contactor feedback), 5 (Brake contactor feedback), 6 (Brake travel switch feedback),
7 (Shorting PMSM stator contactor feedback), and 8 (Shorting door lock circuit contactor
feedback) are valid.
FA-26 Input state 1 FA-27 Input state 2
No. Function No. Function No. Function No. Function
0 Reserved 8
Shorting door lock
circuit contactor
feedback
0 Down limit signal 8
Door 1 close
limit
1 Up leveling signal 9 Inspection signal 1
Up slow-down
signal
9
Door 2 close
limit
2
Down leveling
signal
10 Inspection up 2
Down slow-down
signal
10
Door machine 1
light curtain
3 Door zone signal 11 Inspection down 3 Overload signal 11
Door machine 2
light curtain
4
RUN contactor
feedback
12
Fire emergency
signal
4 Full-load signal 12 Attendant signal
5
Brake contactor
feedback
13 Reserved 5
Emergency stop
signal
13
Direct travel
ride signal
6
Brake travel
switch feedback
14 Elevator lock 6 Door 1 open limit 14
Direction
change signal
7
Shorting PMSM
stator contactor
feedback
15 Up limit signal 7 Door 2 open limit 15
Independent
running
FA-28 Input state 3 FA-29 Input state 4
No. Function No. Function No. Function No. Function
0 Door 2 selection 8 Motor overheat 0 Virtual oor 8 Reserved
1 UPS input 9 Door 1 safety edge 1 Fireghter switch 9 Reserved
2 Door open button 10 Door 2 safety edge 2
Brake travel switch
feedback 2
10 Reserved
3 Door close button 11 Earthquake signal 3 Reserved 11 Reserved
4 Safety circuit 12
Back door
forbidden
4 Reserved 12 Reserved
5
Door lock circuit
1
13 Half-load signal 5 Reserved 13 Reserved
6
Door lock circuit
2
14
Single/Double door
selection
6 Reserved 14 Reserved
7 Half-load signal 15
Fire emergency
oor switchover
7 Reserved 15 Reserved
