- 157 -
FA-30 Input state 5 FA-31 Output state 1
No. Function No. Function No. Function No. Function
0 Reserved 8 Reserved 0 Reserved 8 Door 2 open
1
Higher-voltage
safety circuit
9 Reserved 1 RUN contactor 9 Door 2 close
2
Higher-voltage
door lock circuit 1
10 Reserved 2 Brake contactor 10
Low 7-segment
a display output
3
Higher-voltage
door lock circuit 2
11 Reserved 3
Higher-voltage
startup of brake
11
Low 7-segment
b display output
4 Reserved 12 Reserved 4 Fan/Lamp output 12
Low 7-segment
c display output
5 Reserved 13 Reserved 5
Shorting PMSM
stator contactor
output
13
Low 7-segment
d display output
6 Reserved 14 Reserved 6 Door 1 open 14
Low 7-segment
e display output
7 Reserved 15 Reserved 7 Door 1 close 15
Low 7-segment
f display output
FA-32 Output state 2 FA-33 Output state 3
No. Function No. Function No. Function No. Function
0
Low 7-segment g
display output
8 Full-load output 0
Emergency
evacuation at
power failure
8 Reserved
1
Up arrow display
output
9 Inspection output 1
Forced door close
1
9
High 7-segment
a display output
2
Down arrow
output
10 Fan/Lamp output 2 2
Forced door close
2
10
High 7-segment
b display output
3
Minus sign
display output
11
Shorting door lock
circuit contactor
output
3 Faulty state 11
High 7-segment
c display output
4
Returning to
base oor at
re emergency
output
12
BCD/Gray code/7-
segment c ode
high-bit output
4 Up signal 12
High 7-segment
d display output
5 Buzzer output 13
Controller normal
running output
active
5
Medical sterilization
output
13
High 7-segment
e display output
6 Overload output 14 Electric lock output 6
Non-door zone stop
output
14
High 7-segment
f display output
7
Arrival gong
output
15 Reserved 7
Non-service state
output
15
High 7-segment
g display output
The input/output signals of all floors are viewed in FA-34 to FA-40, as described in the
following table.
