Final Tests
3-47
3
Motion 4000
50 Floor 50 -12.0 in +5880.0 in +12000.0 in
51 Floor 51 -12.0 in +6000.0 in +12000.0 in
52 Floor 52 -12.0 in +6120.0 in +12000.0 in
53 Floor 53 -12.0 in +6240.0 in +12000.0 in
54 Floor 54 -12.0 in +6360.0 in +12000.0 in
55 Floor 55 -12.0 in +6480.0 in +12000.0 in
56 Floor 56 -12.0 in +6600.0 in +12000.0 in
57 Floor 57 -12.0 in +6600.0 in +12000.0 in
58 Floor 58 -12.0 in +6720.0 in +12000.0 in
59 Floor 59 -12.0 in +6840.0 in +12000.0 in
60 Floor 60 -12.0 in +6960.0 in +12000.0 in
61 Floor 61 -12.0 in +7080.0 in +12000.0 in
62 Floor 62 -12.0 in +7200.0 in +12000.0 in
63 Floor 63 -12.0 in +7320.0 in +12000.0 in
64 Floor 64 -12.0 in +7440.0 in +12000.0 in
65 Bottom access distance 0.0 in +120.0 in +12000.0 in
66 Top access distance 0.0 in +120.0 in +12000.0 in
67 Counterweight position 0.0 in +540.0 in +12000.0 in
68
Directional limit
distance
0.0 in +2.0 in +1200.0 in
69 U/DETS VIRTUAL UNUSED, VIRTUAL, PHYSICAL
70 U/DNT1 VIRTUAL UNUSED, VIRTUAL, PHYSICAL
71 U/DNT2 UNUSED UNUSED, VIRTUAL, PHYSICAL
72 U/DNT3 UNUSED UNUSED, VIRTUAL, PHYSICAL
73 U/DNTS UNUSED UNUSED, VIRTUAL, PHYSICAL
74 U/DNT5 UNUSED UNUSED, VIRTUAL, PHYSICAL
75 UETS speed 0 fpm +332 fpm +900 fpm
76 UETS distance -1200.0 in +48.0 in +1200.0 in
77 UETS delta distance -120.0 in +6.0 in +120.0 in
78 UETS delta speed 0 fpm 20 fpm +900 fpm
79 UNTS1 speed 0 fpm 0 fpm +900 fpm
80 UNTS1 distance -1200.0 in +104.5 in +1200.0 in
81 UNTS1 delta distance -120.0 in +6.0 in +120.0 in
82 UNTS1 delta low speed 0 fpm 10 fpm +900 fpm
83 UNTS1 delta high speed 0 fpm 20 fpm +900 fpm
84 UNTS2 speed 0 fpm 0 fpm +900 fpm
85 UNTS2 distance -1200.0 in 0.0 in +1200.0 in
86 UNTS2 delta distance -120.0 in +6.0 in +120.0 in
87 UNTS2 delta low speed 0 fpm 10 fpm +900 fpm
88 UNTS2 delta high speed 0 fpm 20 fpm +900 fpm
89 UNTS3 speed 0 fpm 0 fpm +900 fpm
90 UNTS3 distance -1200.0 in 0.0 in +1200.0 in
91 UNTS3 delta distance -120.0 in +6.0 in +120.0 in
Table 3.4 F7 Parameters
# Item Min Default Max Notes
