Final Adjustments
3-48 Manual # 42-02-2P24
92 UNTS3 delta low speed 0 fpm 10 fpm +900 fpm
93 UNTS3 delta high speed 0 fpm 20 fpm +900 fpm
94 UNTS4 speed 0 fpm 0 fpm +900 fpm
95 UNTS4 distance -1200.0 in 0.0 in +1200.0 in
96 UNTS4 delta distance -120.0 in +6.0 in +120.0 in
97 UNTS4 delta low speed 0 fpm 10 fpm +900 fpm
98 UNTS4 delta high speed 0 fpm 20 fpm +900 fpm
99 UNTS5 speed 0 fpm 0 fpm +900 fpm
100 UNTS5 distance -1200.0 in 0.0 in +1200.0 in
101 UNTS5 delta distance -120.0 in +6.0 in +120.0 in
102 UNTS5 delta low speed 0 fpm 10 fpm +900 fpm
103 UNTS5 delta high speed 0 fpm 20 fpm +900 fpm
104 DETS speed 0 fpm +332 fpm +900 fpm
105 DETS distance -1200.0 in +48.0 in +1200.0 in
106 DETS delta distance -120.0 in +6.0 in +120.0 in
107 DETS delta speed 0 fpm 20 fpm +900 fpm
108 DNTS1 speed 0 fpm 0 fpm +900 fpm
109 DNTS1 distance -1200.0 in +104.5 in +1200.0 in
110 DNTS1 delta distance -120.0 in +6.0 in +120.0 in
111 DNTS1 delta low speed 0 fpm 0 fpm +900 fpm
112 DNTS1 delta high speed 0 fpm 0 fpm +900 fpm
113 DNTS2 speed 0 fpm 0 fpm +900 fpm
114 DNTS2 distance -1200.0 in 0.0 in +1200.0 in
115 DNTS2 delta distance -120.0 in +6.0 in +120.0 in
116 DNTS2 delta low speed 0 fpm 10 fpm +900 fpm
117 DNTS2 delta high speed 0 fpm 20 fpm +900 fpm
118 DNTS3 speed 0 fpm 0 fpm +900 fpm
119 DNTS3 distance -1200.0 in 0.0 in +1200.0 in
120 DNTS3 delta distance -120.0 in +6.0 in +120.0 in
121 DNTS3 delta low speed 0 fpm 10 fpm +900 fpm
122 DNTS3 delta high speed 0 fpm 20 fpm +900 fpm
123 DNTS4 speed 0 fpm 0 fpm +900 fpm
124 DNTS4 distance -1200.0 in 0.0 in +1200.0 in
125 DNTS4 delta distance -120.0 in +6.0 in +120.0 in
126 DNTS4 delta low speed 0 fpm 10 fpm +900 fpm
127 DNTS4 delta high speed 0 fpm 20 fpm +900 fpm
128 DNTS5 speed 0 fpm 0 fpm +900 fpm
129 DNTS5 distance -1200.0 in 0.0 in +1200.0 in
130 DNTS5 delta distance -120.0 in +6.0 in +120.0 in
131 DNTS5 delta low speed 0 fpm 10 fpm +900 fpm
132 DNTS5 delta high speed 0 fpm 20 fpm +900 fpm
Table 3.4 F7 Parameters
# Item Min Default Max Notes
