Diagnostic Mode
4-9
4
Motion 4000
Table 4.4 Alphabetized Flags, Definitions, and Locations
FLAG Definition Add Pos FLAG Definition Add Pos
ALV Other car alive output 31 5 FRS Fire phase 1 input 24 5
API Alternate Parking Input 33 8 FRSS Fire phase 1 flag 2D 3
AUTO Emergency power auto output 31 3 FWI Fire warning indicator output 25 2
BFD Bottom floor demand flag 2E 5 GED Gong enable down output 20 1
CC Car call flag 21 5 GEDR Gong enable down output rear 10 1
CCA Car call above flag 2A 1 GEU Gong enable up output 20 2
CCB Car call below flag 2A 5 GEUR Gong enable up output rear 10 2
CCC Car call cancel input 38 6 GHT Gong hold timer flag 22 4
CCD Car call disconnect flag 2C 3 GHTR Gong hold timer flag rear 12 4
CCH Car call hold 26 5 GTDE Gong timer down enable 26 2
CCR Car call flag rear 11 5 GTUE Gong timer up enable 26 1
CCT Car call time flag 22 2 H High speed output 2B 4
CCTR Car call time flag rear 12 2 HCDX Hall call disconnect flag 2C 4
CD Car done flag 2F 4 HCR Hall call reject flag 2C 5
CNFG Configuration error flag 38 5 HCT Hall call door time flag 22 3
CSB Car stop switch bypass 23 5 HCTR Hall call door time flag rear 12 3
CSBR Car stop switch bypass rear 13 5 HD High speed delay flag 27 8
CTL Car to lobby input 31 6 HDLYE High speed delay elapsed flag 25 3
CTLDOT Car to lobby door open timer 31 8 HLI Heavy load input 25 5
CTLF Car to lobby function 31 7 HLW Heavy load weigher flag 38 1
CTST Capture for test input 33 3 HML Home landing input 38 8
DBC Door close button input 20 4 HOSP In car hospital emergency input flag 33 1
DBCR Door close button rear 10 4 HOSPH2 Hospital emergency phase 2 flag 33 2
DC Down call flag 21 7 HSEL Hospital service select flag 2B 3
DCA Down call above flag 2A 3 HYD1-TR0 Hydro/Traction flag 2F 6
DCB Down call below flag 2A 7 IN Inspection or access input 27 4
DCC Door close complete flag 23 4 INCF Ind. service car call cancel flag 28 3
DCCR Door close complete flag rear 13 4 IND Independent service input 27 5
DCF Door close function output 22 8 INT Intermediate speed input 24 8
DCFR Door close function output rear 12 8 ISR In service and ready 28 4
DCLC Door close contact input 23 6 ISRT In service truly flag 2C 1
DCLCR Door close contact input rear 13 6 ISV In service flag 2C 2
DCP Door close power output 22 7 LD Level down input 29 7
DCPR Door close power output rear 12 7 LEF Leveling encounter flag 25 4
DCR Down call flag rear 11 7 LFP Lower parking floor flag 26 8
DDF Double ding function flag 28 6 LLI Light load input 28 1
DDP Down direction preference flag 29 5 LLW Light load weighing funct. input flag 28 8
DEADZ Dead zone flag 30 4 LOT Lobby door time 22 5
DELSIM Delta simulation bit 27 2 LOTR Lobby door time rear 12 5
DHEND Door hold end 33 4 LU Level up input 29 3
DHENDR Door hold end rear 33 5 LWCE Load weighing change enable flag 38 2
DHLD Door hold input flag 27 6 MGR Motor generator run flag 2B 5
DHLDI Normal door hold input flag 30 3 MLT Motor limit timer flag 2B 7
DHO Door hold open flag 21 2 NDGBPS Nudging bypass flag 23 2
DHOR Door hold open flag rear 11 2 NDGBPSR Nudging bypass flag rear 13 2
DIN Door open inactive 26 4 NDGF Nudging function flag 30 1
DLI Dispatch Load Input 38 4 NDS Hall door timer non-shorten 21 4
DLK Door lock input 28 7 NDSR Hall door timer non-shorten rear 11 4
DLKS Door lock store bit 27 3 NUDG Nudging output 23 3
DLW Dispatch load weighing function 38 3 NUDGR Nudging output rear 13 3
