User Interface
4-48 Manual # 42-02-2P24
• RETAIN CALLS ON CTL / CTF?
• No: If Car To Lobby or Car To Floor are activated, the car will first service registered
car calls then move to the recall floor. Hall calls will be canceled.
• Yes: If Car To Lobby or Car To Floor are activated, the car will first service registered
car calls then move to the recall floor. Hall calls will be retained and served after the
CTL input is deactivated.
• EARTHQUAKE OPERATION?
• Set to Yes if this job has earthquake operation.
• ASME EARTHQUAKE/CALIF EARTHQUAKE
• Use the S button to select the controlling earthquake code in your location.
• If CALIF code is selected, you will be asked to indicate whether or not the hoist
machine is a “Counterweighted drum machine.” Only jobs that are termed “Counter-
weighted Drum Machines” should set this option to Yes.
California jobs without a drum machine should select ASME EQ and set the remaining
EQ option parameters as needed.
ASME Earthquake: Upon activation of a Seismic switch (SSI input), the elevator in motion con-
tinue to the nearest available floor, open the doors and shut down. If the Counterweight Dis-
placement switch is not activated (CWI), the elevator will be allowed to run at reduced speed on
Automatic Operation.
If the elevator is in motion when the Counterweight Displacement switch is activated (CWI
input) an emergency stop is initiated and then the car will proceed away from the counterweight
at reduced speed to the nearest available floor, open the doors and shut down. For this opera-
tion the Earthquake Direction Switch input (EDS) must be selected. An elevator may be
returned to Normal service by means of the Earthquake Reset button, provided that the Dis-
placement switch (CWI) is no longer activated.
California Earthquake: When CALIF Earthquake Operation is selected upon activation of a
Seismic switch (SSI input), the elevator, if in motion, will pause, then proceed to the nearest
available floor at a speed of not more than 150 ft/min (0.76 m/s) open the doors and shut down.
When a Counterweight Displacement switch is required and the Counterweight Displacement
switch (CWI input) has been activated, the elevator, if in motion, will initiate an emergency stop
and proceed away from the counterweight at reduced speed to the nearest available floor, open
the doors and shut down. For this operation, the Earthquake Direction Switch (EDS) input
must be selected. An elevator may be returned to Normal service using the Earthquake Reset
button, provided that the Displacement switch (CWI) is not activated. When Earthquake Oper-
ation is needed, the appropriate spare inputs should be selected.
