F1: Program Mode
4-47
4
Motion 4000
• ATS. BYPASS SECURITY? YES / NO
• Determines if Elevator Security is bypassed when the car is on Attendant Service
(available only when Security and Attendant Service are enabled).
• CAR TO FLOOR RETURN FLOOR
• Determines the floor to which the car will be returned when the CAR TO FLOOR input
is activated (see CTF in Spare Inputs Menu Options).
• SCROLLING SPEED (NORMAL/FAST/SLOW)
• Messages too long to be fully displayed on the LCD are scrolled. This setting deter-
mines scrolling speed.
• OFRP BETWEEN FLRS
• Sets the floors between which the OFRP output will be triggered. The One Floor Run
Programmable output will then be on while making one-floor runs between desig-
nated floors.
• ENABLE FRONT DOB ON SECURITY?
• When enabled, front door open button will be enabled for all landings including
secured landings. When disabled, door open button is disabled at secured landings
once doors have closed.
• ENABLE REAR DOB ON SECURITY?
• When enabled, rear door open button will be enabled for all landings including
secured landings. When disabled, door open button is disabled at secured landings
once doors have closed.
• FLR COUNT BELOW FLOOD LEVEL?
• PITFLD spare input required. Indicates the number of floors below flood level and
thereby sets the flood level. The set number of floors from the bottom of the hoistway
will not be serviced when the PITFLD input is active.
• DISABLE TOP FLRS ON PITFLD
• YES/NO - PITFLD spare input required. Prevents the elevator from servicing floors at
the top of the hoistway (determined by FLR COUNT BELOW FLOOD LEVEL) when
the PITFLD input is active, thereby preventing the counterweight from going into the
water.
• CANCEL BOTH HALL (U/D) CALLS
• If set to NO, when the car is servicing a hall call, only the call in the direction of travel
is canceled.
• If set to YES, when the car is servicing a hall call, calls in both up and down directions
are canceled.
