Motion Control Engineering Motion 4000 User Manual

User Interface
4-72 Manual # 42-02-2P24
200
Faults (01 - 16):
01 = Maximum position offset fault
02 = Minimum position offset fault
03 = Landing system fault (emergency
brake dropped)
04 = Landing system communication loss
fault
05 = Unintended motion
06 = SPC is offline
07 = SPB is offline
08 = (n/a)
09 = Inspection over-speed
10 = Contract over-speed
11 = Leveling over-speed
12 = EEPROM CRC error
13 = EEPROM device error
14 = ETS shutdown
15 = UETS over-speed
16 = UETS position error
201
Faults (17 - 32):
01 = DETS over-speed
02 = DETS position error
03 = Emergency brake cycle test fault
04 = PMDD contactor pick monitor fault
05 = PMDD contactor drop monitor fault
06 = 2L bus monitor fault
07 = RGOK fault (emergency brake
dropped)
08 = Actual and requested direction mis-
match
09 = Excessive faults shutdown
10 = 2MV bus monitor fault
11 = EBPS monitor fault
12 = UNTS-L over-speed
13 = UNTS-H over-speed
14 = UNTS position error
15 = DNTS-L over-speed
16 = DNTS-H over-speed
202
Faults (33 - 48):
01 = DNTS position error
02 = RGOK monitor fault
03 = (n/a)
04 = (n/a)
05 = (n/a)
06 = (n/a)
07 = (n/a)
08 = (n/a)
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = (n/a)
16 = (n/a)
Table 4.12 MPI-A Diagnostics
