Motion Control Engineering Motion 4000 User Manual

F5 Menus
4-73
4
Motion 4000
203 Faults (49 - 64): (n/a)
300
16 = BRE (MPI-A)
15 = DRE (MPI-A)
14 = PME (MPI-A)
13 = DRE (MPI-C)
12 = BRE (MPI-C)
11 = PME (MPI-C)
10 = (n/a)
09 = (n/a)
08 = (n/a)
07 = (n/a)
06 = (n/a)
05 = (n/a)
04 = (n/a)
03 = Danger
02 = Fault
01 = Ready
301
16 = (n/a)
15 = (n/a)
14 = (n/a)
13 = Up slowdown
12 = Down slowdown
11 = Up direction limit
10 = Down direction limit
09 = Front level up
08 = Front door zone
07 = Front level down
06 = Rear level up
05 = Rear door zone
04 = Rear level down
03 = High speed
02 = Up
01 = Down
302
16 = (n/a)
15 = (n/a)
14 = (n/a)
13 = (n/a)
12 = (n/a)
11 = (n/a)
10 = Up slowdown
09 = Down slowdown
08 = Near top
07 = Near bottom
06 = Up direction limit
05 = Down direction limit
04 = Front door zone
03 = Rear door zone
02 = Up
01 = Down
Table 4.12 MPI-A Diagnostics
Address Item Notes
