Motion Control Engineering Motion 4000 User Manual

User Interface
4-74 Manual # 42-02-2P24
303
16 = UETS status
15 = UTS1 status
14 = UNTS2 status
13 = UNTS3 status
12 = UNTS4 status
11 = UNTS5 status
10 = DETS status
09 = DTS1 status
08 = DNTS2 status
07 = DNTS3 status
06 = DNTS4 status
05 = DNTS5 status
04 = Front door zone
03 = Rear door zone
02 = Up
01 = Down
304
16 = In rear floor zone
15 = In front floor zone
14 = Emergency brake: check relay fault
13 = Emergency brake: floor unintended
motion
12 = Emergency brake: door unintended
motion
11 = Emergency brake: governor over-
speed
10 = Zone failure
09 = Rear gate failure
08 = Rear lock failure
07 = Front gate failure
06 = Front lock failure
05 = Emergency brake armed
04 = Rear door open
03 = Front door open
02 = In rear door zone
01 = In front door zone
400 Down distance @ 100% of contract speed
401 Down distance @ 90% of contract speed
402 Down distance @ 80% of contract speed
403 Down distance @ 70% of contract speed
404 Down distance @ 60% of contract speed
405 Down distance @ 50% of contract speed
406 Down distance @ 40% of contract speed
407 Down distance @ 30% of contract speed
408 Down distance @ 20% of contract speed
409 Down distance @ 10% of contract speed
410 Up distance @ 100% of contract speed
411 Up distance @ 90% of contract speed
412 Up distance @ 80% of contract speed
413 Up distance @ 70% of contract speed
Table 4.12 MPI-A Diagnostics
Address Item Notes
