Motion Control Engineering Motion 4000 User Manual

User Interface
4-80 Manual # 42-02-2P24
116
Port G outputs:
01 = (n/a)
02 = (n/a)
03 = DIA4B
04 = DIA3B
05 = (n/a)
06 = (n/a)
07 = (n/a)
08 = (n/a)
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = (n/a)
16 = (n/a)
200
Faults (01 - 16):
01 = Maximum position offset fault
02 = Minimum position offset fault
03 = Landing system fault (emergency
brake dropped)
04 = Landing system communication loss
fault
05 = Unintended motion
06 = SPC is offline
07 = SPA is offline
08 = (n/a)
09 = Inspection over-speed
10 = Contract over-speed
11 = Leveling over-speed
12 = EEPROM CRC error
13 = EEPROM device error
14 = ETS shutdown
15 = UETS over-speed
16 = UETS position error
Table 4.13 MPI-B Diagnostics
Address Item Notes
