Motion Control Engineering Motion 4000 User Manual

User Interface
4-82 Manual # 42-02-2P24
301
16 = (n/a)
15 = (n/a)
14 = (n/a)
13 = Up slowdown
12 = Down slowdown
11 = Up direction limit
10 = Down direction limit
09 = Front level up
08 = Front door zone
07 = Front level down
06 = Rear level up
05 = Rear door zone
04 = Rear level down
03 = High speed
02 = Up
01 = Down
302
16 = (n/a)
15 = (n/a)
14 = (n/a)
13 = (n/a)
12 = (n/a)
11 = (n/a)
10 = Up slowdown
09 = Down slowdown
08 = Near top
07 = Near bottom
06 = Up direction limit
05 = Down direction limit
04 = Front door zone
03 = Rear door zone
02 = Up
01 = Down
303
16 = UETS status
15 = UTS1 status
14 = UNTS2 status
13 = UNTS3 status
12 = UNTS4 status
11 = UNTS5 status
10 = DETS status
09 = DNTS1 status
08 = DNTS2 status
07 = DNTS3 status
06 = DNTS4 status
05 = DNTS5 status
04 = Front door zone
03 = Rear door zone
02 = Up
01 = Down
400 Down distance @ 100% of contract speed
401 Down distance @ 90% of contract speed
402 Down distance @ 80% of contract speed
403 Down distance @ 70% of contract speed
Table 4.13 MPI-B Diagnostics
Address Item Notes
