Motion Control Engineering Motion 4000 User Manual

User Interface
4-90 Manual # 42-02-2P24
133
01 = Near top
02 = Near bottom
03 = High speed
04 = Up direction limit
05 = Down direction limit
06 = Wind
07 = (n/a)
08 = (n/a)
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = (n/a)
16 = (n/a)
200
Faults (01-16):
01 = Motor contactor pick fault
02 = Motor contactor drop fault
03 = Brake contactor pick fault
04 = Brake contactor drop fault
05 = Motor contactor pick proofing fault
06 = Motor contactor drop proofing fault
07 = Brake contactor pick proofing fault
08 = Brake contactor drop proofing fault
09 = Drive not ready
10 = Drive fault
11 = Drive on fault
12 = Drive off fault
13 = Receive communication fault
14 = Transmit communication fault
15 = EEPROM CRC fault
16 = EEPROM device fault
201
Faults (17 - 32):
01 = Drive position mode fault
02 = Inspection over-speed fault
03 = Contract over-speed fault
04 = Excessive faults shutdown
05 = Landing system A position deviation fault
06 = Landing system B position deviation fault
07 = (n/a)
08 = (n/a)
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = (n/a)
16 = (n/a)
202 Faults (33 - 48): (n/a)
203 Faults (49 - 64): (n/a)
Table 4.14 MPI-C Diagnostics
Address Item Notes
