Motion Control Engineering Motion 4000 User Manual

F5 Menus
4-91
4
Motion 4000
300
16 = Up
15 = Down
14 = High speed
13 = (n/a)
12 = (n/a)
11 = (n/a)
10 = (n/a)
09 = Normal run
08 = Correction run
07 = Inspection run
06 = Terminal
05 = Danger
04 = System Ready
03 = Ready
02 = System fault
01 = Fault
301
16 = Up
15 = Down
14 = High speed
13 = Front level up
12 = Front door zone
11 = Front level down
10 = Rear level up
09 = Rear door zone
08 = Rear level down
07 = (n/a)
06 = Terminal
05 = Danger
04 = System ready
03 = Ready
02 = System fault
01 = Fault
302
16 = Up
15 = Down
14 = High speed
13 = Motor contactor monitor
12 = Motor contactor proofing
11 = Motor contactor
10 = Drive active
09 = Drive on monitor
08 = Drive enable
07 = Drive on
06 = Brake contactor monitor
05 = Brake contactor proofing
04 = Brake contactor
03 = Brake enable
02 = Brake pick
01 = Brake on
303
Machine:
25-32 = Brake State
17-24 = Motor State
09-16 = Machine State
01-08 = Machine Command
Table 4.14 MPI-C Diagnostics
Address Item Notes
