User Interface
4-92 Manual # 42-02-2P24
420 Upper Elgo sensor position in m/in
Example: 1.019M. Processed raw position for MPI-
B and MPI-C. Median for MPI-A.
421 Lower Elgo sensor position in m/in
Example: 0.859M. Processed raw position for MPI-
A and MPI-C. Median for MPI-B.
422 Elgo sensor offset in m/in
Distance between upper and lower sensors. About
+160mm for short Elgo sensor head and
+240mm for long sensor head.
423 Median sensor position in m/in Upper sensor position for MPI-C.
424 Brake command signal
425 Brake command voltage
426 Brake command lift rate
427 Brake command drop rate
428 Brake pick voltage
429 Brake hold voltage
430 Brake relevel voltage
431 Brake lift rate
432 Brake drop rate
900 Software ID
901 Software Revision
902 Firmware Revision
903 Hardware Revision
990 Maximum Speed Highest speed attained. Reset MPI-C to clear.
991 Movements Initiated on Inspection Reset MPI-C to clear.
992 Corrections Initiated Reset MPI-C to clear.
993 Relevels Initiated Reset MPI-C to clear.
994 Movements Initiated on Automatic Reset MPI-C to clear.
Table 4.14 MPI-C Diagnostics
Address Item Notes
