F5 Menus
4-105
4
Motion 4000
850 Rear Floor 21 Floor height (inch or mm)
851 Measured magnet length in counts
852 Floor height in counts
853 DLM edge in counts
854 ULM_edge in counts
860 Rear Floor 22 Floor height (inch or mm)
861 Measured magnet length in counts
862 Floor height in counts
863 DLM edge in counts
864 ULM_edge in counts
870 Rear Floor 23 Floor height (inch or mm)
871 Measured magnet length in counts
872 Floor height in counts
873 DLM edge in counts
874 ULM_edge in counts
880 Rear Floor 24 Floor height (inch or mm)
881 Measured magnet length in counts
882 Floor height in counts
883 DLM edge in counts
884 ULM_edge in counts
890 Rear Floor 25 Floor height (inch or mm)
891 Measured magnet length in counts
892 Floor height in counts
893 DLM edge in counts
894 ULM_edge in counts
900 Rear Floor 26 Floor height (inch or mm)
901 Measured magnet length in counts
902 Floor height in counts
903 DLM edge in counts
904 ULM_edge in counts
910 Rear Floor 27 Floor height (inch or mm)
911 Measured magnet length in counts
912 Floor height in counts
913 DLM edge in counts
914 ULM_edge in counts
920 Rear Floor 28 Floor height (inch or mm)
Table 4.15 LS-EDGE Diagnostics
Address Floor number Diagnostic
To Next Page
