User Interface
4-106 Manual # 42-02-2P24
921 Measured magnet length in counts
922 Floor height in counts
923 DLM edge in counts
924 ULM_edge in counts
930 Rear Floor 29 Floor height (inch or mm)
931 Measured magnet length in counts
932 Floor height in counts
933 DLM edge in counts
934 ULM_edge in counts
940 Rear Floor 30 Floor height (inch or mm)
941 Measured magnet length in counts
942 Floor height in counts
943 DLM edge in counts
944 ULM_edge in counts
950 Rear Floor 31 Floor height (inch or mm)
951 Measured magnet length in counts
952 Floor height in counts
953 DLM edge in counts
954 ULM_edge in counts
960 Rear Floor 32 Floor height (inch or mm)
961 Measured magnet length in counts
962 Floor height in counts
963 DLM edge in counts
964 ULM_edge in counts
970 Rear Floor 33 Floor height (inch or mm)
971 Measured magnet length in counts
972 Floor height in counts
973 DLM edge in counts
974 ULM_edge in counts
980 Rear Floor 34 Floor height (inch or mm)
981 Measured magnet length in counts
982 Floor height in counts
983 DLM edge in counts
984 ULM_edge in counts
990 Rear Floor 35 Floor height (inch or mm)
991 Measured magnet length in counts
Table 4.15 LS-EDGE Diagnostics
Address Floor number Diagnostic
