Motion Control Engineering Motion 4000 User Manual

Status and Error Messages
5-11
5
Motion 4000
FCL 1 - 4 LOAD EXTREME UNDER CURRENT
Description: The addressed brake module has detected that delivered current is less than 40% of the
learned operating current. The car will stop at the next landing. First and second consecutive occurrence
faults reset automatically after 8 seconds. If the module consecutively faults again, fault “Brake Module
Fault Limit Reached” is issued and must be reset on the HC-CTL board.
Troubleshooting: Check the brake for proper operation according to manufacturer specifications.
FCL 1 - 4 LOAD EXTREME UNDER VOLTAGE
Description: The addressed brake module has detected delivered voltage is less than 40% of the learned
operating voltage. The car will stop at the next landing. First and second consecutive occurrence faults
reset automatically after 8 seconds. If the module consecutively faults again, fault “Brake Module Fault
Limit Reached” is issued and must be reset on the HC-CTL board.
Troubleshooting: Check the brake for proper operation according to manufacturer specifications.
FCL 1 - 4 - LOAD OVER CURRENT
Description: The addressed brake module has detected excessive current conditions (>20 A during the
first 5 seconds of operation or >15 A after the first 5 seconds of operation). The module is rated at 15 A
continuous operation and, after the first five seconds of operation current is automatically restricted to this
level. The car will stop at the next landing. Three consecutive occurrence faults reset automatically after 8
seconds. If the module consecutively faults again, fault “Brake Module Fault Limit Reached” is issued and
must be reset on the HC-CTL board.
Troubleshooting:
1. Check for a shorted brake control wire.
2. Check that the brake does not require more current than 15A. If so, a second module may be required
in tandem with the first to handle current requirements.
FCL 1 - 4 - LOAD OVER VOLTAGE
Description: The addressed brake module has detected excessive voltage conditions (>310 VDC for 5
seconds or more). Voltage will be automatically limited to 310 VDC when this fault is issued. The car will
stop at the next landing. Three consecutive occurrence faults reset automatically after 8 seconds. If the
module consecutively faults again, fault “Brake Module Fault Limit Reached” is issued and must be reset on
the HC-CTL board.
Troubleshooting:
1. Check that the brake is operating properly.
2. Check that the brake springs are correctly torqued.
FCL 1 - 4 - LOAD UNDER CURRENT
Description: The addressed brake module has detected delivered current is less than 80% of the learned
operating current. The car will stop at the next destination. Three consecutive occurrence faults reset auto-
matically after 8 seconds. If the module consecutively faults again, fault “Brake Module Fault Limit
Reached” is issued and must be reset on the HC-CTL board.
Troubleshooting: Check the brake for proper operation according to manufacturer specifications.
FCL 1 - 4 - LOAD UNDER VOLTAGE
Description: The addressed brake module has detected that delivered voltage is less than 80% of the
learned operating voltage. The car will stop at the next destination. Three consecutive occurrence faults
reset automatically after 8 seconds. If the module consecutively faults again, fault “Brake Module Fault
Limit Reached” is issued and must be reset on the HC-CTL board.
Troubleshooting: Check the brake for proper operation according to manufacturer specifications.
Table 5.1 Status and Error Messages
Scrolling Message - Special Event Message
