PC Board Quick References
5-45
5
Motion 4000
J15 1 Spare Out 1 (Do not connect to 1 Bus)
2Spare Out 2 (Do not connect to 2 Bus)
3Spare Out 3
4Spare Out 4
J16 Used to program the U53 microcontroller
J27
(1-20)
upper
connector
CCB Fire Car Call Cancel Button (input)
FRSA Fire Service Alternate Initiating Device, machine room (input)
FRSM Fire Service Main Initiating Device, all other hoistway fire service initiating
devices (input)
FRES Fire Service Reset (input)
2FS Fire Service Bus
2FS Fire Service Bus
ICPU/GP1 In-Car Panel Inspection Up Direction/General Purpose (Input)
INCP In-Car Panel Inspection (Input)
2HA Hoistway Access Power (Input)
2HA Hoistway Access Power (Input)
INCT Car Top Inspection
ICPD/GP2 In-Car Panel Inspection Down Direction/General Purpose (Input)
ICTD Car Top Inspection Down Direction (Input)
ICTU Car Top Inspection Up Direction (Input)
ABD Bottom Hoistway Access Down Direction (Input)
ABU Bottom Hoistway Access Up Direction (Input)
ATD Top Hoistway Access Down Direction (Input)
ATU Top Hoistway Access Up Direction (Input)
INA Hoistway Access Inspection Up Direction (Input)
TAB Top Access 2nd Pole (Input)
Table 5.3 HC-CTL Board Terminals
Connector Terminal Description
