Motion Control Engineering Motion 4000

Troubleshooting
5-44 Manual # 42-02-2P24
J12
(1-16)
upper
connector
GS Gate Switch (input)
- No connection
DCMS Door Contact Middle String (input)
- No connection
DCAT Door Contact Access Top (input)
- No connection
DCAB Door Contact Access Bottom (input)
- No connection
DLAB Bottom Door Lock (input)
- No connection
DLAT Top Door Lock (input)
- No connection
BAB Bottom Access 2nd Pole
- No connection
SUA Up Direction Arrow (output)
SDA Down Direction Arrow (output)
J12
(17-32)
lower
connector
2S 120VAC for gate switch, inspection access switch, and door locks (output)
- No connection
STD Step Down (input), hydraulic only
STU Step Up (input), hydraulic only
SAFH Hoistway Safety String (input)
SAFC Car Safety String (input)
ESC Hoistway Safety (input)
DLM Level Down (input)
ULM Level Up (input)
DZF Front Door Zone (input)
22 Bus
2S 2S safety bus
- No connection
PFG Passing Floor Gong (output)
GEU Gong Enable Up (output)
GED Gong Enable Down (output)
J14 ESC Hoistway Safety (input)
- No connection
DZF Front Door Zone (input)
- No connection
- No connection
Table 5.3 HC-CTL Board Terminals
Connector Terminal Description
