PC Board Quick References
5-47
5
Motion 4000
J43 OFF MCE connections for Fire Service (See J27)
FRS MCE connections for Fire Service (See J27)
FRA MCE connections for Fire Service (See J27)
FRON MCE connections for Fire Service (See J27)
FCS MCE connections for Fire Service (See J27)
FSLL MCE connections for Fire Service (See J27)
FSLC MCE connections for Fire Service (See J27)
FWI MCE connections for Fire Service (See J27)
1 MCE connections for Fire Service (See J27)
1 MCE connections for Fire Service (See J27)
Table 5.4 HC-CTL Board Indicators
Indicator Description
NUDG Nudge output on
DCP Door Close Power input is high
DCF Door Close Function input is high
DOF Door Open Function input is high
DCL Door Close Limit input is high
DOL Door Open Limit input is high
DPM Door Position Monitor input is high
SE Safety Edge input is high
PHE Photo Eye input is high
TEST Test Mode switch is in ON position
IND Independent Service Operation
DCB Door Close Button
DOB Door Open Button
CCB Fire car call cancel input is active
FCS Phase II Fire Service Operation On (On position of 3-position fire service operation switch)
input is high
HLD Phase II Fire Service Operation Hold (Hold position of 3-position fire service operation
switch) input is high
OFF Phase II Fire Service Operation Off (Off position of 3-position fire service operation switch)
input is high
FWI Fire Service Buzzer
FSLC C.O.P. Fire Service Light input is high
FSLL Fire Service Lobby Light is active
FRA Fire service alternate initiating device on main landing input is high
FRS Fire service main landing initiating device input is high
FRSA Fire service alternate initiating device machine room input is high
FRSM Fire service alternate initiating device in hoistway input is high
Table 5.3 HC-CTL Board Terminals
Connector Terminal Description
